    3. SMD LED 1615 red ice blue two-color highlight 0603 red ice blue two-color SMD LED

    SMD LED 1615 red ice blue two-color highlight 0603 red ice blue two-color SMD LED

    0.0 0
    Private Label Made Simple.
    Your logo, your packaging. Our team can confirm which items support customization and what quantities apply.

    Still deciding? Order a sample

    We understand every decision counts. Test the product first so you can move forward with confidence.

    correlated color temperature (1) *
    • product_attribute_68d29e48cc0bd01d86abea4b
    Quantity: (Min 1000)
    Availability: 989999 in stock
    Products subtotal: $10.00
    Est. Landed Cost
    Included in Every Order
    Show Details Details
    Factory-Direct Access to 1688
    Supplier Verification & Transparency
    Secure Payment with Escrow Protection
    Order Verification Before Shipment
    Consolidated Shipping
    Flexible Delivery Options
    Shipment Tracking
    Full Support from Sourcing to Shipping
    Supplier Info Products specifications Description Reviews (0) Category Insights
    Products specifications Description Reviews (0) Category Insights

    Supplier info

    Returning Customers
    59%
    Overall Service
    5
    Product Accuracy
    5

    Product specifications

    Origin:
    China
    Import or not:
    No
    Order No.:
    HBL
    Brand:
    SURRE BRIGHT/Tengsheng
    Item No.:
    HBL
    Model:
    1615 red ice blue double color
    Dimensions:
    1.6*1.5*0.58
    Power:
    0.06
    color rendering index:
    80
    luminous flux:
    R:70-250 BG:200-500
    Forward voltage:
    R:1.8-2.5 BG:2.6-3.2
    Reverse voltage:
    5
    Electrostatic breakdown voltage (ESD):
    2000
    Rated current:
    20 mA
    Chip Brand:
    Sanan
    Chip Size:
    8
    Phosphor brand:
    Riya
    Glue brand:
    Dao Kangming
    Conductor Material:
    alloy wire
    Bracket material:
    Copper
    Luminous angle:
    120
    luminous efficiency:
    110
    color tolerance:
    5
    Thermal resistance:
    ≤5
    Maximum allowable junction temperature:
    240
    1000 hours conventional aging:
    100
    6000 hours conventional aging:
    98
    Whether the LM-80 test is passed:
    No
    color temperature interval:
    R:620-625 BG:480-495
    correlated color temperature:
    Red ice blue (R:620-625 BG:480-495)1PCS
    Whether the source of cross-border export is exclusive:
    No

    Description

    SMD LED 1615 Red Ice Blue Two-Color High-Bright 0603 Red Ice Blue Two-Color SMD Light Emitting Diode
    Picture of SMD LED 1615 red ice blue two-color highlight 0603 red ice blue two-color SMD LED

    Reviews

    There are no reviews yet
